A lighter, faster, and simpler to adjust stock for your AR
At only eight ounces, the MOE® Trigger Release (TR) is one of Magpul’s lightest stocks. Thanks to its ambidextrous, textured Trigger Release adjustment mechanism, it’s also one of the easiest for making LOP adjustments, as well as installing or removing the stock.
The Trigger Release combines with a newly developed takedown lever that also makes the MOE TR stock our easiest stock to install and remove on your firearm. That means no more leveraging a high-tension spring to mount and remove your stock; the innovative, one-handed toolless takedown lever allows quick and easy installation and removal. It includes a “padlock” icon to indicate whether the stock is locked or unlocked. Once the lever is positioned in the “locked” position, it can’t be removed from the receiver extension, ensuring it won’t slide off when making LOP adjustments. The takedown lever is also partially recessed to minimize snagging while still permitting easy access to select it when necessary.
For sling attachment, the TR includes ambidextrous M-LOK® slots on each side of rear of the stock that function as a footman’s loop or a space to attach M-LOK QD Sling Mounts.
Made in the USA.
NEW TRIGGER RELEASE SLIDER MECHANISM
Ambidextrous sliding, textured, low-profile control trigger pulls double duty as a simple one-handed LOP adjustment lever, as well as allows for toolless installation and removal
EASY INSTALLATION
A takedown lever on the bottom of the stock permits full retraction of the trigger so the stock can slide on and off the receiver extension with minimal effort
The takedown lever's position is indicated with a padlock icon showing the trigger’s status for installation or LOP adjustment
MINIMALIST, LIGHTWEIGHT DESIGN
One of the lightest MOE stocks created at only 8.0 ounces
CUSTOMIZABLE
Compatible with Magpul ASAP®, ASAP® QD and other receiver-mount sling attachments
Rear ambidextrous M-LOK® slots function as a footman's loop for direct sling attachment, and can also accept optional M-LOK QD Sling Mounts for push-button swivels
Compatible with MOE SL® Enhanced Rubber Butt-Pad, 0.70" for additional LOP
Technical Specifications
| Collection | Collapsible Non-Storage AR Stocks |
|---|---|
| Platform | AR10, AR15, M4, M16, M110, SR25 |
| Compatibility | Mil-Spec sized carbine receiver extension tube (not included) from manufacturers such as Colt, LMT, Ruger, S&W, SIG, and others* |
| LOP, M4 Collapsed | ~10.5 in. |
| LOP, M4 Extended | ~13.8 in. |
| LOP Adjustment Range | 3.3 in. |
| Length, max | 7.0 in. |
| Height, max | 5.3 in. |
| Weight | 8.0 oz. |
| Weight, w/ receiver extension | ~11.8 oz. |
| Width, max | 1.6 in. |
| Other Specs |
*NOTE: There are two basic sizes of M4 Carbine receiver extensions (buffer tubes): Mil-Spec and Commercial-Spec. The MOE TR Carbine Stock will only fit with the common Mil-Spec tube. Specifications based on standard-length (flat-back) M4 Carbine receiver extension and may vary depending on tube manufacturer. Will not interfere with single-point slings attached to ASAP or ASAP QD receiver end plates. |
