- Bow mode uses the distance and the angle of a shot to calculate a ballistic equivalent to the target for more accurate uphill and downhill archery shots.
LED
- LED displays use a red numbers and letters and have adjustable brightness settings to optimize readability in changing light conditions.
- Trig-Horizontal uses inclinometer technology to provide the horizontal range to the target, which compensates for uphill and downhill shots in most situations, instead of a standard line of sight distance.
Finish | Black/Black |
---|---|
Magnification | 0 |
Tripod Compatible (1/4-20) | No |
True Ballistic Range - Wind (TBR-W) | No |
True Ballistic Range (TBR) | No |
Archer's Advantage | No |
True Golf Range (TGR) | No |
Line of Sight (LOS) | No |
Trophy Scale | No |
Flight Path | No |
Last Target Mode | No |
Prism Lock | No |
Battery Type | CR2 |
Display Color | OLED (Red Display) |
Length (in) | 2.8 |
Width (in) | 2.3 |
Height (in) | 1.2 |
Weight (oz) | 11 |
Objective Diameter (mm) | 0 |
Linear FOV (ft@1000 yd) | 0 |
Angular FOV (Degrees) | 0 |
Eye Relief (mm) | 0 |
Min Diopter (dpt) | 0 |
Max Diopter (dpt) | 0 |
Light Transmission (%) | 0 |
Battery Life (Actuations) | >3000 |
Accuracy to 125 (yd) | 1 |
Accuracy to 1000 (yd) | 0 |
Accuracy above 1000 (yd) % | 0 |
Max Range - Deer (yd) | 75 |
Max Range - Trees (yd) | 75 |
Max Range - Reflective (yd) | 75 |
Max Range - Golf Flag (yd) | 0 |
Min Range (yd) | 10 |
Laser Classification | IEC 3R |
