- Bow mode uses the distance and the angle of a shot to calculate a ballistic equivalent to the target for more accurate uphill and downhill archery shots.
LED
- LED displays use a red numbers and letters and have adjustable brightness settings to optimize readability in changing light conditions.
- Trig-Horizontal uses inclinometer technology to provide the horizontal range to the target, which compensates for uphill and downhill shots in most situations, instead of a standard line of sight distance.
| Finish | Black/Black |
|---|---|
| Magnification | 0 |
| Tripod Compatible (1/4-20) | No |
| True Ballistic Range - Wind (TBR-W) | No |
| True Ballistic Range (TBR) | No |
| Archer's Advantage | No |
| True Golf Range (TGR) | No |
| Line of Sight (LOS) | No |
| Trophy Scale | No |
| Flight Path | No |
| Last Target Mode | No |
| Prism Lock | No |
| Battery Type | CR2 |
| Display Color | OLED (Red Display) |
| Length (in) | 2.8 |
| Width (in) | 2.3 |
| Height (in) | 1.2 |
| Weight (oz) | 11 |
| Objective Diameter (mm) | 0 |
| Linear FOV (ft@1000 yd) | 0 |
| Angular FOV (Degrees) | 0 |
| Eye Relief (mm) | 0 |
| Min Diopter (dpt) | 0 |
| Max Diopter (dpt) | 0 |
| Light Transmission (%) | 0 |
| Battery Life (Actuations) | >3000 |
| Accuracy to 125 (yd) | 1 |
| Accuracy to 1000 (yd) | 0 |
| Accuracy above 1000 (yd) % | 0 |
| Max Range - Deer (yd) | 75 |
| Max Range - Trees (yd) | 75 |
| Max Range - Reflective (yd) | 75 |
| Max Range - Golf Flag (yd) | 0 |
| Min Range (yd) | 10 |
| Laser Classification | IEC 3R |
