The Strike Dual Folding Adapter is the first-in-market patented system that has an intuitive unfolding system for a Picatinny interface. The Strike Dual Folding Adapter folds left or right anytime without flipping or reconfiguring the hinge. At any moment, the user can fold to the desired left or right side. When moved into the folded position, there is a positive lock so the Strike Dual Folding Adapter remains folded.
A simple pull up on the bar near the hinge and back for quick deployment when folded. A 3-degree down tilt angle is added to help prevent interference with the weapons ejection port when folded to the right side. The Strike Dual Folding Adapter mounts directly to a 1913 Picatinny interface with two (x2) built-in locking lugs for a secure attachment. For the stock rear piece, included is a rear rubber anti-slip buttpad to create the best possible shoulder weld for rifle or registered Short-Barrel Rifle (SBR) setups.
A single QD point is located on the rear of the stabilizer and ambidextrous QD sling mounting points for the stock. The Strike Dual Folding Adapter is constructed with a steel hinge and 6061-T6 Aluminum base, adapter & strut. Get a unique modular system with interchangeable (sold separately) parts like optional cheek riser (to be only used legally with stock setup), strut lengths and other accessories.
Use with almost any 1913 Picatinny rear end like the Strike AR Picatinny Stock Adapter or many factory OEM weapons with a Picatinny rail section in place of the traditional AR buffer tube threads. The Strike Dual Folding Adapter is a one of a kind adapter that gives you more options than anything on the market for those who want a truly modular folder that is under 10 ounces.
NOTE:
-Pressing buttons simultaneously will remove bar from hinge
-Lubrication of hinge and button components needed for routine maintenance
Package Contents:
-x1 Strike Dual Folding Adapter (fully assembled with stabilizer)
-x1 Stock buttpad for rifle or registered Short-Barrel Rifle (SBR)
-x4 Rubber pad (various thickness) for Dual Folding Adapter indentation to adjust desired locking tension when fully deployed
-x1 Torx Tool [T25]
-x1 Warning card
Product Features:
-Preassembled as stabilizer and includes a separate stock rear piece for rifle or registered Short-Barrel Rifle (SBR)
-Patented first-in-market Picatinny dual folding adapter with intuitive unfolding system
-Folds left or right anytime without flipping or reconfiguring hinge
-Adds [Stabilizer] 9.24" (234.64mm) or [Stock] 9.18” (233.14mm) to overall weapon length
-Adds 1.02” (26.00mm) to overall weapon length in folded position
-Positive lock in the folded position, included rubber pads for folding adapter indentation to adjust desired locking tension when fully deployed
-Pull up on bar near hinge and back for quick deployment when folded
-3-degree down tilt to help prevent interference with ejection port when folded to right side
-Mounts directly to 1913 Picatinny interface with 2 built-in locking lugs
-Single rear QD [Stabilizer] and ambidextrous QD sling mounting points [Stock]
-Rubber anti-slip buttpad [Stock]
-Steel hinge with 6061-T6 Aluminum base, adapter & strut
-Lightweight at under 10 ounces
-Modular system with interchangeable parts sold separately (strut, cheek riser, stabilizer & more)
(See additional compatibility list in PRODUCT SPEC tab)
MOUNT COMPATIBILITY: 1913 Picatinny
DISCLAIMER:
-Dirt and/or sand can hinder folding hinge proper operation
-Not recommended for use while mortaring firearm to clear malfunctions
-Expect wear and tear on folding locking mechanism from long term use
-Be careful, avoid fingers from getting caught during folding and unfolding process
OVERALL LENGTH:
-[Stabilizer] adds 9.24" (234.64mm)
-[Stock] adds 9.18” (233.14mm)
to overall weapon length
FOLDED OVERALL LENGTH: adapter adds 1.02” (26.00mm) to overall weapon length in folded position
FULLY ASSEMBLED w/ STABILIZER:
-LENGTH: 240.50mm (9.44")
-WIDTH: 53.05mm (2.09")
-HEIGHT: 141.95mm (5.59")
-WEIGHT: 9.60 oz
FULLY ASSEMBLED w/ STOCK:
-LENGTH: 239.50mm (9.44")
-WIDTH: 53.05mm (2.09")
-HEIGHT: 115.88mm (4.56")
-WEIGHT: 9.90 oz
-WEIGHT W/ PKG: 14.50 oz
MOUNT COMPATIBILITY:
-1913 Picatinny
-Strike AR Picatinny Stock Adapter
-B&T APC9/45, APC223/300, GHM
-Brownells BRN-180 lower receiver
-CZ Bren 2
-CZ Scorpion EVO pistol w/ SI Stock Adapter Back Plate
-Galil ACE
-Ruger PC Charger
-SIG SAUER MCX/MPX
as well as others
