Ultradyne USA Pulse 350 Legend Compensator - Black

Pulse provides exceptional performance in a compact design. Gases are strategically diverted away and out of the shooters line of sight. Pulse strongly reduces recoil and minimizes muzzle rise helping the shooter get back on target quicker to ensure a more accurate followup shots. The PULSE is proof that good things do come in small packages!  A timing nut is included for easy installation. Available in .223/5.56, .308/7.62, 350 Legend.

COMPACT DESIGN
High performance in a compact design

Pulse 350 Legend Technical Specs

• CALIBER
  • Rated for the 350 Legend
• MINIMUM BARREL LENGTH   12″
• BARREL THREAD  *1/2-28 UNEF-2B*
• BARREL THREAD LENGTH MINIMUM    .600″
• MATERIAL
  • 416 Stainless Steel
  • Salt Bath Nitride Finish
• MOUNTING *Crush Washer*
• MASS
  • Brake Only 92 grams | 3.3 ounces
  • Total 118 grams | 3.4 ounces
• DIMENSIONS
  • Length 57mm | 2.25 inches
  • OD 25mm | 0..975 inches
• WRENCH FLATS 13/16 inch

Installation Instructions For Crush Washer:

1. 1. Inspect and clean threads on barrel and muzzle device.
   2. Place the crush washer cone forward over the muzzle threads, then thread the muzzle device up against the crush washer.
   3. Hand tighten the muzzle device and note that crush must be flush with barrel shoulder and fully depress the detent.
   4. Using a wrench, turn the muzzle device 1/4 turn, then continue to tighten to index properly. If the muzzle device is tightened past desired position, start over with a new crush washer.
   5. Check concentricity with a bore alignment rod.
   6. Test fire at 25 yards into a paper target backed up by a minimum 15′ x 15′ safety berm capable of safely stopping projectiles. Verify the ability to shoot groups and inspect for baffle strikes for all loads that will be used.
