Winchester Optics

Winchester Optics Supreme 1-4x24mm Rifle Scope - 30MM Main Tube, Illuminated Reticle, Black

MSRP: $279.95
$229.99
( saved $49.96 )
No reviews yet Write a Review
Adding to cart… The item has been added
SKU:
WQRSSPRM514X24IR
UPC:
840369202291
  • $7.95 Flat Rate Shipping

  • Easy Returns

  • Safe Payments

  • The Best Products

Winchester Supreme quality and performance at the range and in the field ensures you have a dependable optic to trust on your favorite rifle, for your next great adventure on paper or game.

Premium lenses transmit the maximum amount of light to your eye through our Winchester WINcoat™ multicoating. This coating not only reduces harsh glare but carrier accurate color while providing a durable scratch resistant coating to exterior lens surfaces.

Winchester Supreme riflescopes utilize Second Focal Place (SFP) reticles. This means that the reticle stays the same size throughout the scope's magnification range, while only the image changes size. This allows for the most precise shot placement at any distance, and the reticle will always have the same appearance.

Key Features:

  • Fully multi-coated lenses throughout the optical system.
  • Excellent low light performance.
  • Beryllium bronze springs.
  • One-piece housing machined from tough A6063-T6 aluminum.
  • Black anodized aluminum exterior.
  • Designed to stand up to 800 Gs of recoil for standard & magnum rifles, and muzzleloaders.
  • Nitrogen filled and sealed optical system for fog and water.
  • Smooth fast focus eyepiece adjustment.
  • Knurled power adjustment ring and turret knobs for a secure grip.
  • Fingertip turret adjustment for windage and elevation.
  • Zero reset turrets can quickly be adjusted back to zero with a screwdriver or coin.
  • Lens cover, cleaning cloth, user manual and battery included.



SPECS

WINCHESTER® SUPREME® RIFLESCOPE

1-4x24 mm IR

(Illuminated Reticle)

MAGNIFICATION RANGE

1X-4X

OBJECTIVE LENS DIAMETER

24 mm

OBJECTIVE OUTSIDE DIAMETER

30 mm

OCULAR LENS DIAMETER

35.5 mm

OCULAR OUTSIDE DIAMETER

44 mm

BODY TUBE DIAMETER

30 mm

LENGTH

241.7 mm / 9.5 mm

WEIGHT

459 g / 16.2 oz

CONSTRUCTION MATERIAL

A6063-T6

BODY CONSTRUCTION

1 Piece

COLOR / FINISH

Black Matte

WATERPROOF

YES

FOGPROOF

YES

SHOCKPROOF

YES

SIDE FOCUS

NA

PARALLAX ADJUSTMENT

NA

PARALLAX ADJUSTMENT RANGE

NA

PARALLAX SETTING

100 y

ADJUSTMENT TURRET TYPE

Low Turret-Finger Adjustable

WINDAGE ADJUSTMENT RANGE

200 MOA

HORIZONTAL EFFECTIVE RANGE

±60 MOA

ELEVATION ADJUSTMENT RANGE

200 MOA

EFFECTIVE VERTICAL ADJUSTMENT RANGE

±60 MOA

CLICK VALUE

0.5 MOA

RETICLE TYPE (ETCHED / WIRE)

Etched

RETICLE DESIGN

Illuminated

EYE RELIEF

116-98 mm / 4.6” - 3.8”

EXIT PUPIL

24 mm - 6 mm

FIELD OF VIEW (FOV)

116.6 ft - 28.8 ft

FOCAL PLANE

Second (SFP)

DIOPTER COMPENSATION

+2/-2.5

BATTERY

CR2032

ZERO STOP

NO

THREADED FOR SUNSHADE

NO

RESETTABLE TURRET

YES

IP RATING

IPX7 (1m/30min)

FULL MULTICOAT TYPE

Winchester WINcoat™
