The RICO BRAVO is a groundbreaking thermal imaging riflescope featuring innovative ergonomics, cutting-edge connectivity, and InfiRay’s MATRIX III algorithm that pushes the boundaries of 384x288 long-wave performance. The BRAVO is optically and electronically optimized to squeeze every ounce of performance out of InfiRay’s MICRO II 12 μm sensor and F1.1 germanium lens.
iRayUSA’s all new Magnetic Omnidirectional Connector, Hard Stop Buttons, and Tactile Ridge Positioning system combine to create an unmatched user experience on a high-definition display.Additional performance-focused design features include multiple dynamic reticles, stadiametric rangefinder, image and video capture, wireless connectivity, and an American Defense Manufacturing RQD quick release mount. If you are looking for a lightweight and compact thermal optic that is designed by hunters for hunters, look no further than the RICO BRAVO.
| GENERAL | |
|---|---|
| MPN | RB35 |
| UPC | 850029093114 |
| SENSOR | |
| Resolution | 384×288 |
| Pixel Size | 12 µm |
| Frame Rate | 50hz |
| Image Processing | MATRIX III |
| Core | iRay Micro II 384 |
| OPTICS | |
| Objective Lens | 35mm F1.1 |
| Optical Magnification | 3X |
| Digital Zoom | 4X, stepped |
| FOV | 7.5° x 5.7° |
| Detection Range | 1750 Yards |
| Display Type | High-Definition |
| Display Resolution | 1280×960 |
| Imaging Modes | White Hot, Black Hot, Red Hot, Color, Highlight |
| Reticle Types | 7 (2 Dynamic, 5 Static) |
| Reticle Colors | Black, White, Red, Green |
| Mounting System | Picatinny, MIL-STD 1913 / ADM RQD Mount |
| Picture-in-Picture | Yes |
| Rangefinder | Stadiametric |
| Eye Relief | 40mm |
| Diopter Range | -4 to +4 |
| ELECTRONICS | |
| Onboard Recording | Video and Image |
| Wireless Connectivity | Video and Image via App |
| Data/Power Connector | Magnetic Omnidirectional Connector |
| Power Supply | CR123A x2 USB via Magnetic Omnidirectional Connector |
| Start Up Time | > 10 Seconds, Instant from Standby |
| PHYSICAL & ENVIRONMENTAL | |
| Size | 7.78”×2.79”×3.13” |
| Weight | 21.2 ounces (with Batteries) |
| Housing Material | Ultra Rigid, Glass-Filled Polymer |
| Ingress Protection | IP67 |
| Operation Temp | -4°F to 122°F |
| Max. Recoil | 1000 g/s² (300 Win./7mm Mag) |
| Warranty | 5 Years |
