DNT Optics TNC635R ThermNight Black 1.5-6x 35mm 640x512, 12 Microns, 60 Hz Resolution - SKU: TNC635R - UPC: 850065096117
Product Description
The DNT Optics TNC635R ThermNight is a state-of-the-art multispectral digital sighting system that seamlessly merges high-resolution thermal imaging, full-color day digital optics, and high-sensitivity night vision into a single streamlined riflescope. Powered by an ultra-sensitive 640x512 VOx thermal sensor with a 12-micron pixel pitch and a rapid 60 Hz frame rate, this flagship optic delivers buttery-smooth thermal detection and exceptional target detail across extended distances, even through smoke, fog, and dense cover.
Equipped with a premium 35mm F/1.0 Germanium objective lens, the TNC635R offers a versatile 1.5x to 6x optical-to-digital magnification range. The ThermNight system allows operators to run independent thermal or digital night vision channels, or layer them together via Picture-in-Picture (PiP) and optical fusion modes onto the ultra-clear 1920x1080 OLED micro-display. An integrated laser rangefinder (LRF) measures distances instantly out to 1,000+ yards, feeding real-time data into the onboard ballistic engine to automatically project corrected holdover points directly onto the reticle.
Encased in a aircraft-grade aluminum alloy housing with an IP67 waterproof rating, the TNC635R is built to withstand extreme recoil forces up to .300 Win Mag / .338 Lapua. Powered by rechargeable, field-replaceable 18650 batteries, the optic features onboard audio/video recording, Wi-Fi streaming via the DNT app, and intuitive controls designed for high-stress nocturnal engagements and predator management.
*Armorer Bench Notes & Real-World Staging Guidance:
Fitment Matrix: Mounts directly to standard MIL-STD-1913 Picatinny rails via the included heavy-duty quick-detach (QD) mount assembly.
- Verify the host firearm is verified safe, magazine removed, and chamber physically confirmed empty.
- Install two fully charged flat-top 18650 lithium-ion batteries into the battery compartments, verifying correct terminal polarity.
- Mount the TNC635R QD base onto the receiver's Picatinny rail, adjusting the QD lever tension thumb screws until the mount clamps firmly without rail play.
- Power on the optic, adjust the ocular focus ring to clarify the OLED display menus, and use the 35mm objective focus ring to sharpen target image geometry.
- Connect to the DNT mobile app via Wi-Fi to input caliber-specific ballistic data (bullet weight, muzzle velocity, sight height) before initiating sight-in and laser rangefinder calibration.
Key Features
- Multispectral Technology: Combines a 640x512 thermal sensor with a 4K digital day/night sensor for dual-channel observation.
- 640x512 12μm 60Hz Thermal Sensor: Flagship thermal core delivers smooth tracking and crisp detail at rapid frame rates.
- Integrated LRF & Ballistic Calculator: Built-in laser rangefinder calculates target distance and provides automated reticle holdover solutions.
- Multi-Channel Display Modes: Toggle between thermal, digital day/night, and Picture-in-Picture (PiP) fusion modes on a 1024/1080 OLED screen.
- Rugged Heavy-Recoil Construction: Aluminum alloy housing is IP67 waterproof and recoil-rated for high-energy centerfire platforms.
Product Specifications
- Brand: DNT Optics
- MPN: TNC635R
- UPC: 850065096117
- Thermal Sensor Resolution: 640 x 512 VOx (12 Micron)
- Frame Rate: 60 Hz
- Magnification Range: 1.5x - 6x
- Objective Lens: 35mm F/1.0 Germanium
- Display: High-Resolution OLED Micro-Display
- Laser Rangefinder Range: 1,000+ Yards
- Power Source: Rechargeable 18650 Batteries / USB-C External 5V
- Waterproof Rating: IP67
- Body Finish: Matte Black Anodized
