Sons of Liberty Gun Works 5.56 NATO M16 Bolt Carrier Group with OCKS Screws - SOLGW-BCG556-OCKS - UPC 657628674153
Product Description
The Sons of Liberty Gun Works OCKS 5.56 Bolt Carrier Group represents the pinnacle of mil-spec duty reliability for the AR-15 platform. Built strictly to USGI Technical Data Package (TDP) standards, this full-auto profile M16 carrier is machined from case-hardened 8620 steel and lined with durable chrome along the gas key and carrier bore. The bolt assembly is shot-peened, individual High-Pressure Tested (HPT), and Magnetic Particle Inspected (MPI) Carpenter No. 158 steel, ensuring zero hidden micro-fractures and exceptional fatigue life under violent cyclic pressure.
The defining feature of this upgraded carrier group is the integration of Michiguns Optimized Carrier Key Screws (OCKS). Featuring twelve sharp splines under the head and deep mechanical staking channels, the OCKS screws allow carrier key metal to flow directly into the splines during the staking process. Combined with proper torque specs and high-temp threadlocker, this aggressive staking prevents carrier key backing out—one of the single most common failure points in hard-use AR-15 gas systems.
Finished in standard MIL-SPEC manganese phosphate, this BCG holds lubricant exceptionally well for reduced friction and seamless cycling under sustained rapid fire. Outfitted with a tool steel extractor, upgraded Sprinco extractor spring, and black insert, the SOLGW OCKS BCG guarantees positive, reliable ejection in extreme suppressed and unsuppressed environments. Hand-inspected in San Antonio, Texas, and backed by SOLGW’s lifetime "no questions asked" warranty, this component is built to run indefinitely.
*Armorer Bench Notes & Real-World Staging Guidance:
Fitment Matrix: Fits all standard mil-spec AR-15, M4, and M16 upper receivers. Compatible with 5.56 NATO, .223 Remington, and .300 AAC Blackout barrels/calibers.
Staging & Maintenance Steps:
- Prior to first live-fire staging, strip the factory storage oil and apply a generous coat of high-viscosity synthetic gun lubricant to the four carrier contact rails, bolt tail, and cam pin hole.
- Inspect the OCKS carrier key staking to verify metal displacement into the screw splines.
- Ensure the gas rings are staggered 120 degrees apart on the bolt tail to maintain optimal seal integrity.
- Verify function: slide the bolt fully forward in the carrier; place the carrier vertically on its bolt face. If the carrier stays upright under its own weight without collapsing, gas ring tension is within duty tolerance.
Key Features
- Full-auto M16 profile carrier machined from 8620 case-hardened steel.
- Carpenter No. 158 steel bolt, individual High-Pressure Tested (HPT) and Magnetic Particle Inspected (MPI).
- Upgraded with Michiguns Optimized Carrier Key Screws (OCKS) and heavy dual-point mechanical staking.
- Manganese phosphate exterior finish with chrome-lined gas key and carrier bore for superior gas containment.
- Tool steel extractor equipped with upgraded Sprinco extra-power extractor spring and black insert.
- Shot-peened bolt assembly for enhanced resistance to stress fractures and metal fatigue.
Product Specifications
- Brand: Sons of Liberty Gun Works (SOLGW)
- Model: M16 5.56 Bolt Carrier Group with OCKS Upgrade
- MPN: SOLGW-BCG556-OCKS
- UPC: 657628674153
- Caliber Compatibility: 5.56 NATO / .223 Rem / .300 Blackout
- Carrier Material: 8620 Steel (Chrome Lined)
- Bolt Material: Carpenter No. 158 Steel
- Finish: MIL-SPEC Manganese Phosphate
- Profile: Full-Auto / M16
- Origin: Made in USA
